This is our standard 1,000 KG/H PP PE film washing line.
PE Film Washing Line Diagram
[click to enlarge diagram]
Machinery List / Specifications / Quotation
| Machine Description | Specifications | Qty (piece) | Price (USD) | Total (USD) |
| 1. Belt Conveyor w/ Magnetic Drum (model#PS-L-800) |
1) belt width: 800㎜ 2) belt material: PVC (scrapper height: 50mm, space:500mm) 3) belt thickness: 5mm 4) belt perimeter: 13000mm 3) motor power: 3KW 4) reduction ratio: 1: 30 5) drive roll diameter: φ250㎜ 6) belt linear velocity: 0.56m/s |
1 | $9,000 | $9,000 |
| 2. Plastic Granulator (model#SWHB1000) |
1) main motor power: 75KW 2) cutter head rotary diameter: φ630㎜ 3) cutter head width: 960㎜ 4) No. of rotating knife: 15pcs 5) No. Of static knife: 4pcs 6) cutter material: SKD11 7) cutter head rotating speed: 462rpm 8) cutter head material: 45 steel 9) screen hole: φ50㎜ 10) open feeding hopper/ hydraulic screen way: mechanical type 11) Cover open motor power: 0.75KW 12) Screen change motor power: 0.37KW |
1 | $25,000 | $25,000 |
| 3. Air Blower (model#FS) |
1) blower power: 5.5KW 2) pipe diameter: φ159㎜ 3) pipe material: stainless steel 4) pipe length: 22mm |
1 | $3,500 | $3,500 |
| 4. Washing Tank (model#QXC1500) |
1）Width inside: 1500㎜ 2）Total length: 6000㎜ 3）Material: 2.5mm stainless steel 4）Frame material: carbon steel 5）Bottom screw motor: 2.2KW 6）Bottom screw reducer model: NMRV130-60-B3.20 7）Discharge material screw motor: 4KW 8）Discharge material reducer model: NMRV130-30-B3.20 9）Lifting dirt screw motor power: 2.2KW 10）Lifting dirt screw reducer model: NMRV110-60-B3.20 11）Scraper drive motor power: 4KW 12）Scraper drive reducer model: NMRV130-60-V3.21 13) Scatter drum motor power: 2.2KW 14) Scatter drum reducer model: UDL-2.2-NMRV090-15-V3.14 |
1 | $34,000 | $34,000 |
| 5. High Speed Friction Washer (model#HXJ1000) |
1) rotor rotary diameter: φ750㎜ 2) rotor material: 45steel( parkerizing) 3) rotor rotating speed: 1080rpm 4) No. of rotor blade: 63 pcs 5) rotor blade material: 304 6) frame material: carbon steel 7) motor power: 45KW |
1 | $22,000 | $22,000 |
| 6. De-watering Machine (model#TS1000) |
1) rotor rotary diameter: φ750㎜ 2) rotor material: 45steel( parkerizing) 3) rotor rotating speed: 1080rpm 4) No. of rotor blade: 63 pcs 5) rotor blade material: 304 5) frame material: carbon steel 6) motor power: 45KW |
1 | $22,000 | $22,000 |
| 7. Thermal Dryer (model#RSJ) |
1) pipe diameter: φ219㎜ 2) blower power: 4KW 3) pipe material: stainless steel 4) heating power: 72KW |
3 | $5,500 | $16,500 |
| 8. Cyclone Separator w/ Air Locker (model#FL800) |
1) diameter: φ800㎜ 2) material: 2mm Stainless steel 3) air locker motor power: 2.2KW 4) gear box model: NMRV090-30 5) rotary valve diameter: φ500㎜ 6) air locker material: Stainless Steel |
2 | $3,500 | $7,000 |
| 9. Transmit Silo (model#LC2000) |
1) material: 2.5mm Stainless steel 2) diameter: φ2000㎜ 3) volume: 10m3 4) mixing motor power: 4KW 5) mixer rotary speed: 4.5rpm 6) Frame material: Q235 weldment |
2 | $22,000 | $44,000 |
| 10. Agglomerator (model#TLJ1000) |
1) main motor power: 160KW 2) cutter head rotary diameter: 850mm 3) drum diameter: 900mm 4) rotary blades number: 4pcs 5) static blades number: 10pcs 6) blades material: SKD11 7) rotary speed: 780rpm 8) cutter head material: 45 steel |
2 | $22,000 | $44,000 |
| 11. Vibrating Screen (model#ZDS600) |
1) motor power: 0.2KW*2 2) motor rotating speed: 1450rpm 3) vibration force: 2.5KN |
2 | $7,000 | $14,000 |
| 12. Air Blower (model#FS) |
1) blower power: 5.5KW 2) pipe diameter: φ159㎜ 3) pipe material: stainless steel |
1 | $3,500 | $3,500 |
| 13. Feeding Auger (model#LX-273) |
1) screw material: 5mm stainless steel 2) screw diameter: φ273㎜ 3) screw space: 185㎜ 4) motor power: 4KW 5）Barrel diameter: φ273㎜ 6）Barrel material: 3mm stainless steel 7）Auger barrel length: 3500mm |
2 | $5,000 | $10,000 |
| 14. Force Feeder (model#WL)
15. Double Screw Extruder (model#SHJ95) 16. Hydraulic Screen Changer (model#HW180) |
Force Feeder 1) motor power: 7.5KW 2) reduction ratio: 1:10 3) material: 5mm stainless steel 4) screw compress rate: 35x 5) screw rotary speed: 145rpm 6) screw material: 5mm stainless steel 7) bleed pressure: 0.5Mpa 8) air consumption: 50L/min (if needed) Double Screw Extruder Hydraulic Screen Changer |
2 | $90,000 | $180,000 |
| 17. Water Ring Pelletizer (model#HP500)
18. Vibrating Screen (model#ZDS500) |
Water Ring Pelletizer 1) motor power: 2.2KW 2) motor rotating speed: 0~2800rpm 3) timing method: frequency control 4) cutter number: 3 pieces 5）cutter blades: D2 6) bleed pressure: 0.5Mpa 7) air consumption: 1L/hr Vibrating Screen |
2 | $9,500 | $19,000 |
| 19. Vertical Dewatering Machine (model#TS500) |
1) motor power: 7.5KW 2) motor rotating speed: 1080rpm 3) rotor diameter: φ370mm 4) rotor material: stainless steel 5) blades number: 60pcs 6) blades material: stainless steel |
2 | $8,000 | $16,000 |
| 20. Air Blower (model#FS) |
1) blower power: 5.5KW 2) pipe diameter: φ159㎜ 3) pipe material: stainless steel 4) pipe length: 22mm |
2 | $3,500 | $7,000 |
| 21. Finished Product Silo (model#FS) |
1) silo material: stainless steel 2) silo volume: 2m3 3) frame material: carbon steel |
2 | $3,000 | $6,000 |
| 22. Electrical Control Panel |
1) main circuit: button switch,circuit breaker,motor starters, AC contactors (manufactured by Siemens) 2) control loop part: micro-relay, (manufactured by Siemens) 3) power switch, (manufactured by Siemens) 4) PLC,converter, (manufactured by Siemens) 5) voltage, current meter (manufactured by Autonils, Korea & Eurotherm, UK respectively) 6) support materials, wiring terminals, rail, etc. (manufactured by WeiZhe,Taiwan) |
4 | $20,000 | $80,000 |
| 23. Water Recycling / Filtration System (optional) |
Primary Filter 1) main motor power: 1.5KW 2) blower power: 0.55KW 3) screw diameter: φ245mm 4) screw material: stainless steel 304 5) screw rotating speed: 5.8rpm 6) filtering area: 2.5m2 7) filtering screen size: 80mesh 8) frame material: A3 9) water tank volume: 2m3 10) water tank material: carbon steel Intermediate Pump Air Floatation Pond Clean Water Tank Clean Water Pump |
1 | $75,000 | $75,000 |
| Totals | Installed Power (Washing Line): 1382.5KW Installed Power (Filtration): 33KW Capacity: 800 – 1,000 KG/h |
$637,500 |
Ordering
- Quotation is for FOB Port of Shanghai.
- Payment Terms: 30% of the total contract price as down payment (T/T). The balance 70% of total contract price should be paid upon picking up the goods (T/T).
- Delivery: 60-90 working days after receiving the down payment.
- Price Validity: Prices listed on this webpage are a close approximation only. Final contract value will be determined based on your specifications.
- Warranty: One Year
- Packing: Wooden Cases
- The spare parts are available upon request.
Frequently Asked Questions
What equipment is included in the 1000 kg/h PP PE film washing line?
The line comprises 23 machine groups: belt conveyor with magnetic drum, SWHB1000 plastic granulator, QXC1500 float-sink separation tank, HXJ1000 high-speed friction washer, TS1000 dewatering machine, thermal dryers, cyclone separators, transmit silos, TLJ1000 agglomerators, vibrating screens, a force feeder with SHJ95 double screw extruder and hydraulic screen changer, HP500 water ring pelletizer, vertical dewatering machine, air blowers, finished product silo, electrical control panel, and an optional water recycling/filtration system.
What capacity and power does the line require?
Rated capacity is 800–1000 kg/h. Total installed power is 1382.5 kW for the washing line plus 33 kW for the optional filtration system — plan your electrical supply and transformer capacity accordingly before installation.
What is the total investment for this line?
The listed machinery totals $637,500 FOB Port of Shanghai, including the optional $75,000 water recycling/filtration system. Prices on the page are a close approximation only; the final contract value is determined based on your specifications.
What are the ordering and delivery terms?
Quotation is FOB Port of Shanghai with 30% down payment (T/T) and the 70% balance paid upon pickup. Delivery is 60–90 working days after receiving the down payment. Warranty is one year, packing is in wooden cases, and spare parts are available on request.
Is water recycling included?
An optional Water Recycling / Filtration System ($75,000) is available, with a primary filter, intermediate pumps, an air flotation pond (16 m³/h, 0.4 MPa), a 17 m³ clean water tank, and clean water pumps. It lets the line recirculate wash water instead of discharging it, cutting water costs and environmental load.
What is the end product of the line?
Washed PP/PE film is agglomerated, then pelletized through the double screw extruder with hydraulic screen changer and water ring pelletizer, producing finished plastic pellets collected in the product silo — ready for resale or reuse in manufacturing.
